ASRock Rack 1U Rackmount 1U12XL-EPYC/2T2E

Name: ASRock Rack 1U Rackmount 1U12XL-EPYC/2T2E
SKU: 794838227
Price: 287486 JPY
Availability: InStock

元の価格は ¥487,201 でした。現在の価格は ¥287,486 です。

-41%

メーカー名: ASRock Rack

商品コード: PC4950

説明

・1U Chassis support 3.5” or 2.5” SATA/SAS HDD/SSD Hot-Swap Bay + 2 x 2.5” NVME SSD Hot-Swap Bay with 700W Redundant PSU

・Single Socket SP3(LGA4094) support AMD EPYC 7002/7001 series processor family

・Supports 8 Channels DDR4 3200/2933/2666/2400 RDIMM, LRDIMM 8 x DIMM slots

・2 x 2.5’’ Hot-Swap Bay in the front, 12 Bay multi-function Hot-Swappable Bay for 3.5” or 2.5” SATA/SAS HDD/SSD

・ASPEED 2500. Integrated IPMI 2.0 with KVM, vMedia and Dedicated LAN (RTL8211E)

System	Form Factor – 1U Rackmount Chassis Model – 1U12L Dimensions – 860 x 438.5 x 43.2 mm (33.9 x 17.2 x 1.7 inches) Support MB – EPYCD8-2T (12” x 9.6”)’ (EPYCD8-2T)
Front Panel	Buttons – Power On/Off button – UID button – System reset button LEDs – 1 x Power status LED – 1 x LAN activity LED – 1 x HDD status LED I/O Ports -2 x USB 3.0 ports
MB tray	USB 3.0 – 2 Serial Port – 1 x COM port VGA – 1 x D-Sub Lan Port – 2 x RJ45 10G base-T by Intel® X550 – 1 x RJ45 Dedicated IPMI LAN port – LAN Ports with LED (ACT/LINK LED and SPEED LED)
External Drive Bay / Storage	Front Side Drive Bay – 2 Hot-Swappable Bay for 2.5” NVME SSD Front Side Backplane – Dual single Backplanes for each drive Internal Side – 12 Bay multi-function Hot-Swappable Bay for 3.5” or 2.5” SATA/SAS HDD/SSD* 2.5” SATA/SAS HDD/SSD is going to be supported soon. Please contact our sales representatives for the information of when it is available. A raid card is required to support SAS HDD/SSD. How many HDD/SSD are supported vary depending on the type of raid card you use. Internal Side Backplane – 3x Quad ports Backplane for drives* *SFF-8482 connector
Power Supply	Type – 1U, Redundant Output Watts – 700W
System Fan	Fan – 40 x 28 mm Fan x6
Physical Status	Form Factor – ATX Dimensions – 12” x 9.6” (30.5 cm x 24.4 cm)
Processor System	CPU – AMD EPYC™ 7002/7001 series processor family Socket – Single Socket SP3 (LGA4094)
System Memory	Capacity – 8 DIMM slots Type – Eight Channel DDR4 memory technology – Supports DDR4 RDIMM and LRDIMM DIMM Size Per DIMM – RDIMM: 32GB, 16GB, 8GB – LRDIMM: 128GB, 32GB DIMM Frequency – RDIMM: 2666/2400MHz – LRDIMM: 2666/2400MHz Voltage – 1.2V
Expansion Slot	PCIe 3.0 x 16 – 1 slot
Storage	OCuLink for U.2 – 2
Ethernet	Interface – – 10000/1000 /100 /10 Mbps by Intel® X550 LAN Controller – 2 x RJ45 10G base-T by Intel® X550 – 1 x RJ45 Dedicated IPMI LAN port by RTL8211E – Supports Wake-On-LAN – Supports Energy E_cient Ethernet 802.3az – Supports Dual LAN with Teaming function – Supports PXE – LAN1 supports NCSI
Management	BMC Controller – ASPEED AST2500 IPMI Dedicated GLAN – 1 x Realtek RTL8211E for dedicated management GLAN Features – Watch Dog – NMI
Graphics	Controller – ASPEED AST2500 VRAM – DDR4 128Mb
Rear Panel I/O	VGA Port – 1 x D-Sub USB 3.2 Gen2 Port – 2 Lan Port – 2+1 RJ45 Gigabit Ethernet LAN port – LAN Ports with LED (ACT/LINK LED and SPEED LED) Serial Port – 1 x COM port UID Button/UID LED – 1
Internal Connector	SATA DOM – 1 M.2 – 2(M2_1: 2230/2242/2260/2280, SATA/PCIE(X4); M2_2:2230/2242/2260/2280/22110, SATA/PCIE(X4)) Front LED – 1 Auxiliary Panel Header – 1 (includes chassis intrusion, location button & LED, and front LAN LED) TR1 Header – 1 TPM Header – 1 IPMB Header – 1 USB 3.2 (Gen1) Header – 1 (supports 2 USB 3.0 ports)
Onboard LED	80 Debug Port LED – 1 Fan Fail LED – 1 (only Fan Fail LED)
System BIOS	BIOS Type – 32MB AMI UEFI Legal BIOS BIOS Features – Plug and Play (PnP) – ACPI 2.0 Compliance Wake Up Events – SMBIOS 2.8 Support – ASRock Rack Instant Flash
Hardware Monitor	Temperature – CPU Temperature Sensing – MB/TR1/Card side Temperature Sensing Fan – CPU/Rear/Front Fan Tachometer – CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU Temperature) – CPU/Rear/Front Fan Multi-Speed Control Voltage – Voltage Monitoring: Vsoc,Vcpu, VCCM, VPPM, 3V/5V/12V, +BAT, 3VSB, 5VSB
Environment	Temperature – Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C
Support OS	Microsoft® Windows® – Server 2012 R2 (64 bit) – Server 2016 (64 bit) Linux – RedHat Enterprise Linux Server 6.9 (64 bit) / 7.3 (64 bit) – CentOS 6.9 (64 bit) / 7. 3 (64 bit) – SUSE Enterprise Linux Server 11 SP4 (64 bit) / 12 SP2 (64 bit) – Ubuntu 16.04 (64 bit) / 17.04 (64 bit) – CITRIX XenServer 7.5 Virtual: – VMWare® ESXi 6.5 u1 – vSphere 6.5 u1 * Please refer to our website for the latest OS support list.

JAN：4717677339697
